Get a better sense of your project cost and materials.


This Charcoal and Teak composite horizontal full privacy fence panel uses five Teak boards and two Charcoal boards. Its joined infill sits in Private Black metal framing. The nominal size is 6 × 3.5 ft.

The composite fence boards have a wood grain texture. Their wood plastic composite core combines natural wood fibers and recycled plastic. See the composite panel overview for the board material.

Powder-coated galvanized steel posts with welded base plates support this Surface Mount composite fence. Pair them with separate black aluminum rails. The finished posts stand 45 inches above ground. Supply ground anchors for each fence section.

  • This Charcoal and Teak composite horizontal full privacy fence panel uses five Teak boards and two Charcoal boards. Its joined infill sits in Private Black metal framing. The nominal size is 6 × 3.5 ft.

    The composite fence boards have a wood grain texture. Their wood plastic composite core combines natural wood fibers and recycled plastic. See the composite panel overview for the board material.

    Powder-coated galvanized steel posts with welded base plates support this Surface Mount composite fence. Pair them with separate black aluminum rails. The finished posts stand 45 inches above ground. Supply ground anchors for each fence section.

  • Engineering Dimensions

    Nominal size (width × height): 6 × 3.5 ft.

    Mounting Type: Surface Mount.

    Fence height: 43 inches.

    Gap below the fence: ½ inch.

    Post spacing (center to center): 71½ inches.

    Clear opening between posts: approximately 68¼ inches.

    Post height above ground: 45 inches, excluding the post cap.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    74-inch Steel Post with Welded Base Plate: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    Top Rail: powder-coated aluminum.

    Bottom Rail: powder-coated aluminum.

    Horizontal Connector: aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Groove Cover: powder-coated aluminum.

    • Seven joined boards create a continuous Teak and Charcoal face.
    • Wood grain texture gives the composite infill a timber look.
    • The boards resist moisture, fading and rot without routine painting or staining.
    • Powder-coated steel posts use welded bases for Surface Mount installation.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Charcoal and Teak boards and covered metal fence parts: up to 25 / 10 years.
    • Covered Charcoal and Teak board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 74-inch galvanized steel fence post with welded base plate and compatible system components

Modern Yard™ 74-Inches Steel Post with Welded Base Plate

Modern Yard horizontal fence rail set with matching rail components on a white background

Modern Yard™ Horizontal Fence Rail Set

Modern Yard Charcoal composite fence board with dark wood-look finish on a white background

Modern Yard™ Charcoal Fence Board (4-Pack)

Modern Yard Teak composite fence board with natural wood-look finish on a white background

Modern Yard™ Teak Fence Board (4-Pack)

Imagine Your Future Fence

Installation Guides

Installation Manual

​Technical Drawing


Frequently Asked Questions

Each color comes in four-board packs. One section needs two Teak packs and one Charcoal pack, leaving three Teak and two Charcoal boards unused. For several composite fence panels, total each color separately and check available stock before rounding to whole packs.

No. Teak and Charcoal name the boards. Private Black names the metal post finish.

Ground anchors for the Teak and Charcoal fence are customer-supplied.
