Redwood Composite Horizontal Full Privacy Single Gate — 3.5 ft W × 3.5 ft H - In-Ground

Style #:

WPH/SGFPRD6-42X42-IG

This composite fence gate uses six joined Redwood pieces for its closed horizontal infill. A welded aluminum frame holds the boards; two powder-coated galvanized steel posts support the standalone gate. Its nominal 3.5 ft height does not mean it blocks every view above the leaf.

The frame comes without boards; order Redwood board packs and the steel posts separately. Browse the composite fence gate options for other configurations.

Redwood boards blend wood fiber with recycled plastic. Their faces need no regular painting, staining or sealing.

  • This composite fence gate uses six joined Redwood pieces for its closed horizontal infill. A welded aluminum frame holds the boards; two powder-coated galvanized steel posts support the standalone gate. Its nominal 3.5 ft height does not mean it blocks every view above the leaf.

    The frame comes without boards; order Redwood board packs and the steel posts separately. Browse the composite fence gate options for other configurations.

    Redwood boards blend wood fiber with recycled plastic. Their faces need no regular painting, staining or sealing.

  • Engineering Dimensions

    Nominal size (width × height): 3.5 × 3.5 ft.

    Mounting Type: In-Ground.

    Gate height: 43¼ inches.

    Gap below the gate: 1½ inches.

    Post spacing (center to center): 45⅝ inches.

    Clear opening between posts: approximately 42⅜ inches.

    Post height above ground: 45 inches, excluding the post cap.

    Post depth below ground: 24 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    42 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    • Six Redwood wood-grain pieces form the closed horizontal infill.
    • The 42-Inch x 42-Inch welded aluminum frame model has factory holes for the supplied hinges and covers.
    • Two steel posts support the standalone gate.
    • Redwood boards resist moisture and decay outdoors.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Redwood board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 98-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 98-Inches Steel Post

Modern Yard Redwood composite fence board with wood-look finish on a white background

Modern Yard™ Redwood Fence Board (4-Pack)

Modern Yard 42 x 42 aluminum gate frame on a white background

Modern Yard™ 42 Inches x 42 Inches Gate Frame

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

No. That is the frame model. The drawing gives approximately 42⅜ inches between posts and 45⅝-inch post-center spacing.

One standalone gate uses six stock Redwood boards, cut into six infill pieces. Two four-board packs supply eight boards, leaving two whole boards.

Yes. A project material quote counts each shared post once. It totals Redwood demand across the order before rounding whole packs.
