Redwood Composite Horizontal Full Privacy Single Gate — 3.5 ft W × 6 ft H - In-Ground

Style #:

WPH/SGFPRD11-42X72-IG

Eleven joined Redwood pieces form this horizontal composite privacy gate at a nominal 3.5 × 6 ft size. A large welded aluminum frame surrounds the board stack, with two galvanized steel posts supporting the composite fence gate.

Order Redwood board packs with the frame, posts and separate combination lock. Three four-board packs provide the stock for this gate's eleven cut pieces. Check the actual frame and post-opening dimensions before installation.

Quote adjoining Redwood fencing with the gate. Count shared posts once, using the specified gate post, and combine Redwood stock before rounding to whole packs. See the composite fence gate options for the horizontal options.

  • Eleven joined Redwood pieces form this horizontal composite privacy gate at a nominal 3.5 × 6 ft size. A large welded aluminum frame surrounds the board stack, with two galvanized steel posts supporting the composite fence gate.

    Order Redwood board packs with the frame, posts and separate combination lock. Three four-board packs provide the stock for this gate's eleven cut pieces. Check the actual frame and post-opening dimensions before installation.

    Quote adjoining Redwood fencing with the gate. Count shared posts once, using the specified gate post, and combine Redwood stock before rounding to whole packs. See the composite fence gate options for the horizontal options.

  • Engineering Dimensions

    Nominal size (width × height): 3.5 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 45½ inches.

    Clear opening between posts: approximately 42⅜ inches.

    Post height above ground: 74 inches, excluding the post cap.

    Post depth below ground: 40 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Mechanical Combination Lock: 304 stainless steel.

    • Eleven Redwood board pieces fill the leaf in horizontal runs.
    • Joined Redwood boards make the infill closed, with no planned view gaps.
    • Two galvanized steel posts support the large aluminum frame.
    • Redwood composite infill resists moisture, fading, insects and rot.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Redwood board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock is outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Redwood composite fence board with wood-look finish on a white background

Modern Yard™ Redwood Fence Board (4-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

No. Eleven original Redwood boards supply eleven cut pieces. Buy three four-board packs for this gate alone; one board remains spare. Follow the gate's cutting guide.

The 3.5 × 6 ft size is nominal, with width first. This gate uses the 71-Inch x 42-Inch frame model. Check the engineering dimensions for the actual opening and installed height.

Use two 114-inch In-Ground steel posts. Confirm the required components in your single-gate estimate.
