Six upright Teak pieces fill each leaf of this composite fence gate. Two welded aluminum frames create the full-privacy double assembly, nominally 7 ft wide by 6 ft high. Teak wood-grain boards fill both leaves.
The wood-plastic composite blends wood fibers and recycled plastic. Its Teak faces resist fading, moisture, insects and rot without regular painting, staining or sealing. Private Black identifies the metal finish, separately from the board color.
Order the two frames and galvanized steel end posts as separate products. Add the active leaf's mechanical combination lock and the inactive leaf's outdoor handle set with drop rod. Assemble the upright infill on site within the welded frames.
Explore the Teak composite fence gate options when choosing the board direction. Clean the Teak faces with mild soap, water and a soft brush or cloth. Avoid harsh chemicals and abrasive tools.
Six upright Teak pieces fill each leaf of this composite fence gate. Two welded aluminum frames create the full-privacy double assembly, nominally 7 ft wide by 6 ft high. Teak wood-grain boards fill both leaves.
The wood-plastic composite blends wood fibers and recycled plastic. Its Teak faces resist fading, moisture, insects and rot without regular painting, staining or sealing. Private Black identifies the metal finish, separately from the board color.
Order the two frames and galvanized steel end posts as separate products. Add the active leaf's mechanical combination lock and the inactive leaf's outdoor handle set with drop rod. Assemble the upright infill on site within the welded frames.
Explore the Teak composite fence gate options when choosing the board direction. Clean the Teak faces with mild soap, water and a soft brush or cloth. Avoid harsh chemicals and abrasive tools.
Engineering Dimensions
Nominal size (width × height): 7 × 6 ft.
Mounting Type: In-Ground.
Gate height: 72 inches.
Gap below the gate: 1 inch.
Post spacing (center to center): 87⅜ inches.
Clear opening between posts: approximately 84¼ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 40 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 28½ / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
114-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
71 x 42-inch Welded Gate Frame: powder-coated aluminum.
Gate Frame Cover Strip: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
#8 x 1-1/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Groove Cover: powder-coated aluminum.
Mechanical Combination Lock: 304 stainless steel.
Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.
#8 x 3/4" ST Screw: 316 stainless steel.
- Teak composite boards stand vertically in both gate leaves.
- Twelve upright Teak pieces join across both leaves, continuing the wood-look pattern through the paired opening.
- Powder-coated aluminum frames surround the composite boards, while steel posts support the paired leaves.
- The vertical Teak infill resists fading, moisture and insect-related damage.
Limited warranty periods (residential / commercial use):
- Structural defects in Teak boards and covered metal gate parts: up to 25 / 10 years.
- Covered Teak board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently asked questions
Is each Teak leaf seven feet wide?
Seven feet is the nominal width across the complete pair. Two large gate frames form the leaves. Use the drawing's 84¼-inch clear opening and 87⅜-inch post spacing to lay out the supports.
How many board and spacer packs does this layout need?
Three four-board Teak packs supply twelve original boards, six for each leaf. No original boards remain unused for the gate alone. The joined vertical infill uses no one-inch view-gap spacers.
What should I include for the inactive leaf?
Order its outdoor handle set with drop rod separately from the active leaf's lock. List both in your Teak gate material request. Include adjoining fence panels in the same plan so the combined fence system counts each shared gate post once.
