Teak Composite Horizontal Full Privacy Double Gate with Crossbeam — 7 ft W × 6 ft H - In-Ground

Style #:

WPH/DGFPTK22-84X72-CB-IG

Horizontal Teak boards fill this composite fence gate below a separate crossbeam. The 22-board count covers the entire double gate. It is a material requirement for assembly into two aluminum frames, rather than the contents of one ready-filled gate package.

Select this crossbeam version for the specified connection to a 7 ft fence. The double fence gate remains nominally 7 ft wide by 6 ft high. Its taller post layout uses 114-inch stock, with 86 inches above ground and 28 inches below. One LINE crossbeam and its installation hardware are additional purchasing entries. The double-gate overview helps separate complete entrance dimensions from individual leaf and component choices.

  • Horizontal Teak boards fill this composite fence gate below a separate crossbeam. The 22-board count covers the entire double gate. It is a material requirement for assembly into two aluminum frames, rather than the contents of one ready-filled gate package.

    Select this crossbeam version for the specified connection to a 7 ft fence. The double fence gate remains nominally 7 ft wide by 6 ft high. Its taller post layout uses 114-inch stock, with 86 inches above ground and 28 inches below. One LINE crossbeam and its installation hardware are additional purchasing entries. The double-gate overview helps separate complete entrance dimensions from individual leaf and component choices.

  • Engineering Dimensions

    Nominal size (width × height): 7 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 87⅛ inches.

    Clear opening between posts: approximately 84 inches.

    Post height above ground: 86 inches, excluding the post cap.

    Crossbeam top: 2 inches below the post top.

    Post depth below ground: 28 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Crossbeam: powder-coated galvanized steel.

    Base Connector: powder-coated aluminum.

    L Connector: 201 stainless steel.

    Mechanical Combination Lock: 304 stainless steel.

    Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.

    #8 x 3/4" ST Screw: 316 stainless steel.

    • Teak composite infill is laid horizontally across both gate leaves.
    • The full configuration calls for 22 boards and two aluminum frames.
    • Only one overhead crossbeam is installed for the paired leaves.
    • The post layout is specific to the gate's connection with a 7 ft fence.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Teak boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Teak board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Teak composite fence board with natural wood-look finish on a white background

Modern Yard™ Teak Fence Board (4-Pack)

Modern Yard LINE 1 x 4 x 8 ft galvanized steel fence slat with dark powder-coated finish

Modern Yard Line™ Fence Slat - 1 in. x 4 in. x 8 ft (2-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard stainless steel outdoor gate handle set with drop rod

Modern Yard™ Stainless Steel Outdoor Gate Handle Set with Drop Rod

Modern Yard full-privacy hardware kit for 1-inch horizontal fence slats

Modern Yard™ Full-Privacy Hardware Kit for 1-Inch Fence Slats

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

No. The boards remain horizontal. The additional beam is above the leaves and does not replace their infill or turn this into a vertical-board gate.

It is the nominal combined width. Leaf height remains nominally 6 ft; the 7 ft figure for the adjacent fence describes the separate junction requirement.

The listed fractions describe the configuration's stock allocation. Purchasing is settled in complete sales packs with the project's actual materials and usable leftovers.
