Redwood Composite Vertical Full Privacy Double Gate — 7 ft W × 6 ft H - In-Ground

Style #:

WPV/DGFPRD12-84X72-IG

Twelve upright Redwood boards form the joined infill of this composite fence gate. Six pieces fill each welded aluminum frame. The nominal 7 × 6 ft double assembly combines Redwood wood-grain faces with Private Black metal framing.

Wood fibers and recycled plastic form the composite boards. The Redwood surfaces resist moisture, insects, rot and fading, and need no regular painting, staining or sealing. Redwood is the selected composite color rather than a solid-timber gate material.

Three four-board packs supply all twelve original boards. Order the two large gate frames and galvanized steel end posts separately. The active leaf uses a mechanical combination lock; the inactive leaf needs the outdoor handle set with drop rod. Both hardware products are separate purchases.

Compare composite double gates in the composite fence gate overview before selecting the infill. Assemble this vertical layout on site. Keep the twelve-board stock requirement when planning the gate with adjoining Redwood composite fencing.

  • Twelve upright Redwood boards form the joined infill of this composite fence gate. Six pieces fill each welded aluminum frame. The nominal 7 × 6 ft double assembly combines Redwood wood-grain faces with Private Black metal framing.

    Wood fibers and recycled plastic form the composite boards. The Redwood surfaces resist moisture, insects, rot and fading, and need no regular painting, staining or sealing. Redwood is the selected composite color rather than a solid-timber gate material.

    Three four-board packs supply all twelve original boards. Order the two large gate frames and galvanized steel end posts separately. The active leaf uses a mechanical combination lock; the inactive leaf needs the outdoor handle set with drop rod. Both hardware products are separate purchases.

    Compare composite double gates in the composite fence gate overview before selecting the infill. Assemble this vertical layout on site. Keep the twelve-board stock requirement when planning the gate with adjoining Redwood composite fencing.

  • Engineering Dimensions

    Nominal size (width × height): 7 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 87⅜ inches.

    Clear opening between posts: approximately 84¼ inches.

    Post height above ground: 74 inches, excluding the post cap.

    Post depth below ground: 40 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Mechanical Combination Lock: 304 stainless steel.

    Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.

    #8 x 3/4" ST Screw: 316 stainless steel.

    • Six joined Redwood pieces fill each upright full-privacy leaf.
    • The wood-grain composite resists fading, moisture, insects and rot.
    • Two welded aluminum frames connect to two galvanized steel end posts.
    • Three four-board packs supply the complete twelve-board infill.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Redwood board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Redwood composite fence board with wood-look finish on a white background

Modern Yard™ Redwood Fence Board (4-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard stainless steel outdoor gate handle set with drop rod

Modern Yard™ Stainless Steel Outdoor Gate Handle Set with Drop Rod

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

The vertical pair needs twelve original Redwood boards, six per leaf. The horizontal full-privacy double gate uses twenty-two pieces and a different cutting plan. Select the board direction before calculating the stock order.

Use mild soap, water and a soft cloth or brush on the board faces. Avoid harsh chemicals and abrasive cleaning tools. The composite needs no routine painting, staining or sealing; follow separate care guidance for the metal frame and hardware.

Keep the two 114-inch gate posts in your vertical Redwood double-gate estimate. They extend 74 inches above ground without caps and 40 inches below. The drawing gives one inch of ground clearance beneath the 72-inch gate. Plan fences and gates in the same layout to count shared supports once. For composite fence systems with a shared connection, retain this gate's specified post.
