Choose a Private Black aluminum double gate for your outdoor spaces. Each leaf arrives with privacy infill and three hinges. Nominal size is 7 × 6 ft.
The leaves are powder coated aluminum. Order the galvanized steel posts, lock and handle set separately.
A separate mechanical combination lock gives keyless access without batteries or wiring. The inactive leaf uses a handle set with drop rod. Compare the Modern Yard aluminum gate formats for other leaf layouts.
Choose a Private Black aluminum double gate for your outdoor spaces. Each leaf arrives with privacy infill and three hinges. Nominal size is 7 × 6 ft.
The leaves are powder coated aluminum. Order the galvanized steel posts, lock and handle set separately.
A separate mechanical combination lock gives keyless access without batteries or wiring. The inactive leaf uses a handle set with drop rod. Compare the Modern Yard aluminum gate formats for other leaf layouts.
Engineering Dimensions
Nominal size (width × height): 7 × 6 ft.
Mounting Type: In-Ground.
Gate height: 72 inches.
Gap below the gate: 1 inch.
Post spacing (center to center): 87⅜ inches.
Clear opening between posts: approximately 84¼ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 40 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 28½ / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
114-inch Steel Post: powder-coated galvanized steel.
71 x 42-inch Pre-Assembled Privacy Gate: powder-coated aluminum.
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Mechanical Combination Lock: 304 stainless steel.
Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.
#8 x 3/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
#8 x 3/4" ST Screw: 316 stainless steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
Groove Cover: powder-coated aluminum.
- Two filled aluminum leaves arrive with their privacy infill preassembled.
- Each leaf includes three hinges for its post connection.
- A powder-coated Private Black finish covers the aluminum gate leaves.
- The separate combination lock gives keyless access without battery replacement.
Limited warranty periods (residential / commercial use):
- Structural defects in covered metal gate parts: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently asked questions
Do I need separate infill packs for the two leaves?
No. The double gates come with their infill fitted. Order posts, the lock and handle set separately.
Is every part of the double gate aluminum?
No. The leaves are aluminum; the posts are galvanized steel. The lock faces, latch, handle and drop rod use 304 stainless steel. The lock also contains other materials.
How do I include the hardware with an adjoining fence?
Include both leaves, two posts, a lock and a handle set in an aluminum double-gate quote. Include connected panels so the fence system counts shared supports once.
