Get a better sense of your project cost and materials.


Redwood Composite Vertical 1 × 6 ft Decorative Panel, Pattern P01 Single Gate with Crossbeam — 3.5 ft W × 6 ft H - In-Ground

Style #:

WPV/SGDP16P01RD4DP1-42X72-CB-IG

Select this Redwood composite fence gate by its vertical P01 infill rather than size alone. Four composite boards and one decorative module form the leaf, using an aluminum frame and matched hinges. That recipe differs from both the six-board plain vertical gate and the nine-board horizontal decorative version.

The separate Crossbeam configuration connects the nominal 6 ft leaf with a 7 ft fence run. It specifies two In-Ground steel posts and a cut LINE member purchased outside the frame product. Compare vertical composite fence layouts for the fixed sections beside the entrance. Compare composite fence gates by their board pack, P01 set and overhead fixings instead of combining quantities from another model.

  • Select this Redwood composite fence gate by its vertical P01 infill rather than size alone. Four composite boards and one decorative module form the leaf, using an aluminum frame and matched hinges. That recipe differs from both the six-board plain vertical gate and the nine-board horizontal decorative version.

    The separate Crossbeam configuration connects the nominal 6 ft leaf with a 7 ft fence run. It specifies two In-Ground steel posts and a cut LINE member purchased outside the frame product. Compare vertical composite fence layouts for the fixed sections beside the entrance. Compare composite fence gates by their board pack, P01 set and overhead fixings instead of combining quantities from another model.

  • Engineering Dimensions

    Nominal size (width × height): 3.5 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 45⅝ inches.

    Clear opening between posts: approximately 42½ inches.

    Post height above ground: 86 inches, excluding the post cap.

    Crossbeam top: 2 inches below the post top.

    Post depth below ground: 28 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Crossbeam: powder-coated galvanized steel.

    Base Connector: powder-coated aluminum.

    L Connector: 201 stainless steel.

    Mechanical Combination Lock: 304 stainless steel.

    Decorative Panel: electrocoated and powder-coated galvanized steel.

    Decorative Panel Top Rail: powder-coated aluminum.

    Decorative Panel Bottom Rail: powder-coated aluminum.

    Decorative Panel Side Rail: powder-coated aluminum.

    • A four-board vertical Redwood recipe is paired with one P01 module.
    • The decorative steel panel remains part of the leaf assembly.
    • The crossbeam uses separate LINE stock and matched fixing components.
    • This identity retains the 6 ft leaf while providing the specified 7 ft fence connection.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Redwood board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock is outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Redwood composite fence board with wood-look finish on a white background

Modern Yard™ Redwood Fence Board (4-Pack)

Modern Yard LINE 1 x 4 x 8 ft galvanized steel fence slat with dark powder-coated finish

Modern Yard Line™ Fence Slat - 1 in. x 4 in. x 8 ft (2-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard 1 x 6 ft decorative fence panel with modern perforated metal design

Modern Yard™ 1 Foot x 6 Feet Fence Decorative Panel

Modern Yard full-privacy hardware kit for 1-inch horizontal fence slats

Modern Yard™ Full-Privacy Hardware Kit for 1-Inch Fence Slats

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

They are different configurations. This model includes the specified overhead arrangement and its own opening and post details for joining a 7 ft fence.

This decorative leaf uses four Redwood boards and one P01 module. The plain vertical full-privacy leaf uses six boards and no decorative module.

One aluminum frame, four Redwood boards and one P01 set form the single leaf. The complete installation separately lists two posts and one overhead crossbeam.
