The Redwood horizontal composite semi-privacy gate has eight 1-inch openings within its leaf. Nine full board pieces and one solid end strip form the infill of this nominal 3.5 × 6 ft composite fence gate, inside a large welded aluminum frame.
Sixteen side-groove spacers set eight clear view openings. The end strip stays solid. Order the spacer pack, Redwood boards, frame, two steel posts and combination lock separately. View composite fence gate formats to compare single- and double-leaf options.
The Redwood horizontal composite semi-privacy gate has eight 1-inch openings within its leaf. Nine full board pieces and one solid end strip form the infill of this nominal 3.5 × 6 ft composite fence gate, inside a large welded aluminum frame.
Sixteen side-groove spacers set eight clear view openings. The end strip stays solid. Order the spacer pack, Redwood boards, frame, two steel posts and combination lock separately. View composite fence gate formats to compare single- and double-leaf options.
Engineering Dimensions
Nominal size (width × height): 3.5 × 6 ft.
Mounting Type: In-Ground.
Gate height: 72 inches.
Gap below the gate: 1 inch.
Post spacing (center to center): 45½ inches.
Clear opening between posts: approximately 42⅜ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 40 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 28½ / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
114-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
71 x 42-inch Welded Gate Frame: powder-coated aluminum.
Gate Frame Cover Strip: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
#8 x 1-1/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Groove Cover: powder-coated aluminum.
Mechanical Combination Lock: 304 stainless steel.
1-inch Composite Spacer: powder-coated aluminum.
- Nine full Redwood pieces and one solid strip complete the large leaf.
- Eight one-inch clear gaps remain within the horizontal infill.
- Sixteen spacers are installed, one at each side of every opening.
- The Redwood infill resists decay, moisture and insect-related damage.
- Modern Yard™ 114-inch Steel Post x 2 PCs
- Modern Yard™ 71-inch x 42-inch Door Frame x 1 set
- Modern Yard™ Redwood Fence Board x 2.5 packs (10 boards)
- Modern Yard™ Stainless Steel Mechanical Combination Lock x 1 set
- Modern Yard™ Accessory – 1-Inch Spacer for Horizontal Fence (40-Pack) x 0.4 pack
Limited warranty periods (residential / commercial use):
- Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
- Covered Redwood board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock is outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently asked questions
Why does the end of the infill use a solid strip?
A solid composite strip finishes the stack, leaving eight clear gaps between the spaced boards.
Is this the same infill as the closed Redwood single gate?
The 3.5 × 6 ft closed Redwood gate uses eleven joined horizontal pieces. This spaced leaf has nine full pieces, one solid strip and eight 1-inch gaps. Its sixteen spacers belong to the semi-privacy arrangement.
Which post dimensions apply to this gate?
Use two 114-inch posts, with 74 inches above ground and 40 inches below. Include both posts in your large Redwood gate quote.
