The large Charcoal horizontal fence gate has a closed composite board stack. Eleven composite pieces fill its welded aluminum frame. This is the nominal 3.5 × 6 ft configuration. Use the drawing's actual opening and installed height for the site layout.
Powder-coated galvanized steel posts support the frame. Order the Charcoal boards and combination lock kit separately from the frame. The kit includes the gate latch. If the gate adjoins fence panels, show their layout in the material request. Review the horizontal composite fence gate layouts for the available board styles.
The large Charcoal horizontal fence gate has a closed composite board stack. Eleven composite pieces fill its welded aluminum frame. This is the nominal 3.5 × 6 ft configuration. Use the drawing's actual opening and installed height for the site layout.
Powder-coated galvanized steel posts support the frame. Order the Charcoal boards and combination lock kit separately from the frame. The kit includes the gate latch. If the gate adjoins fence panels, show their layout in the material request. Review the horizontal composite fence gate layouts for the available board styles.
Engineering Dimensions
Nominal size (width × height): 3.5 × 6 ft.
Mounting Type: In-Ground.
Gate height: 72 inches.
Gap below the gate: 1 inch.
Post spacing (center to center): 45½ inches.
Clear opening between posts: approximately 42⅜ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 40 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 28½ / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
114-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
71 x 42-inch Welded Gate Frame: powder-coated aluminum.
Gate Frame Cover Strip: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
#8 x 1-1/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Groove Cover: powder-coated aluminum.
Mechanical Combination Lock: 304 stainless steel.
- Charcoal composite pieces form horizontal rows in the large single leaf.
- Joined board runs give the Charcoal infill a closed face.
- The Charcoal board material resists fading and insect damage.
- Board care does not call for regular painting, staining or sealing.
- Modern Yard™ 114-inch Steel Post x 2 PCs
- Modern Yard™ 71-inch x 42-inch Door Frame x 1 set
- Modern Yard™ Charcoal Fence Board x 2.75 packs (11 boards)
- Modern Yard™ Stainless Steel Mechanical Combination Lock x 1 set
Limited warranty periods (residential / commercial use):
- Structural defects in Charcoal boards and covered metal gate parts: up to 25 / 10 years.
- Covered Charcoal board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock is outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently asked questions
Should I use an abrasive pad on Charcoal boards?
Wash Charcoal boards with mild soap, water and a soft brush or cloth. Avoid harsh chemicals and abrasive pads. Follow separate care guides for the metal parts and lock.
Is the filled leaf ready-made in this configuration?
No. Buy the board packs separately from the large aluminum frame. Three four-board packs supply eleven Charcoal boards for this gate and one spare.
How do I request the correct privacy version?
Ask for Charcoal, horizontal full privacy and the large single-gate format in your gate component request. The nominal size is 3.5 × 6 ft. Semi-privacy uses a different board and spacer list.
