Teak Composite Horizontal Semi-Privacy Single Gate with 1-Inch Gaps — 3.5 ft W × 3.5 ft H - In-Ground

Style #:

WPH/SGG10TK6-42X42-IG

Four one-inch view gaps separate the Teak infill in this composite fence gate. Five horizontal board pieces and a solid terminal strip fill the nominal 3.5 × 3.5 ft single leaf. Eight aluminum spacers keep the openings at the frame sides.

The Teak composite combines wood fibers and recycled plastic with a wood-grain surface. Its faces resist moisture, insects, rot and fading. A powder-coated aluminum gate frame holds the infill between two galvanized steel posts for In-Ground installation.

Assemble the boards on site within the welded frame. Buy the Teak packs and spacers separately from the frame product. Compare composite fence gate layouts when choosing a board direction and privacy pattern.

Clean the composite faces with mild soap and water and a soft brush or cloth. Avoid abrasive tools and harsh chemicals. The Teak boards need no regular painting, staining or sealing.

  • Four one-inch view gaps separate the Teak infill in this composite fence gate. Five horizontal board pieces and a solid terminal strip fill the nominal 3.5 × 3.5 ft single leaf. Eight aluminum spacers keep the openings at the frame sides.

    The Teak composite combines wood fibers and recycled plastic with a wood-grain surface. Its faces resist moisture, insects, rot and fading. A powder-coated aluminum gate frame holds the infill between two galvanized steel posts for In-Ground installation.

    Assemble the boards on site within the welded frame. Buy the Teak packs and spacers separately from the frame product. Compare composite fence gate layouts when choosing a board direction and privacy pattern.

    Clean the composite faces with mild soap and water and a soft brush or cloth. Avoid abrasive tools and harsh chemicals. The Teak boards need no regular painting, staining or sealing.

  • Engineering Dimensions

    Nominal size (width × height): 3.5 × 3.5 ft.

    Mounting Type: In-Ground.

    Gate height: 43¼ inches.

    Gap below the gate: 1½ inches.

    Post spacing (center to center): 45⅝ inches.

    Clear opening between posts: approximately 42⅜ inches.

    Post height above ground: 45 inches, excluding the post cap.

    Post depth below ground: 24 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    42 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    1-inch Composite Spacer: powder-coated aluminum.

    • Teak wood-grain infill creates the horizontal board face and solid end strip.
    • Four one-inch spaces leave partial views through the single leaf.
    • Eight aluminum spacers hold the gaps within the frame.
    • A welded aluminum gate frame sits between two galvanized steel posts.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Teak boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Teak board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 98-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 98-Inches Steel Post

Modern Yard Teak composite fence board with natural wood-look finish on a white background

Modern Yard™ Teak Fence Board (4-Pack)

Modern Yard 42 x 42 aluminum gate frame on a white background

Modern Yard™ 42 Inches x 42 Inches Gate Frame

Modern Yard 1-inch spacer for horizontal fence installation

Modern Yard™ Accessory – 1-Inch Spacer for Horizontal Fence (40-Pack)

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

One inch describes the four openings between boards. The drawing specifies a separate 1½-inch ground clearance below the leaf.

Five originals supply the board pieces; a sixth supplies the terminal strip. Two four-board Teak packs provide eight originals, leaving two unused for this gate alone. Combine board needs before rounding a larger order.

The spacer product is a separate purchase. Include it when requesting a complete material quote. Count shared support locations once and retain the specified gate post where a fixed fence section joins the leaf.
