Teak wood-grain composite stands upright within this small composite fence gate. Six joined pieces fill a welded aluminum frame in Private Black. The single leaf is nominally 3.5 ft wide and 3.5 ft high, with galvanized steel posts on each side.
The composite combines wood fibers with recycled plastic. Teak faces resist moisture, insects, rot and fading and need no regular painting, staining or sealing. Clean the boards with mild soap, water and a soft brush or cloth, avoiding harsh chemicals and abrasive tools.
The boards, gate frame and post products are separate purchases for on-site assembly. Use the composite fence gate guide to compare the available infill directions and sizes.
Teak wood-grain composite stands upright within this small composite fence gate. Six joined pieces fill a welded aluminum frame in Private Black. The single leaf is nominally 3.5 ft wide and 3.5 ft high, with galvanized steel posts on each side.
The composite combines wood fibers with recycled plastic. Teak faces resist moisture, insects, rot and fading and need no regular painting, staining or sealing. Clean the boards with mild soap, water and a soft brush or cloth, avoiding harsh chemicals and abrasive tools.
The boards, gate frame and post products are separate purchases for on-site assembly. Use the composite fence gate guide to compare the available infill directions and sizes.
Engineering Dimensions
Nominal size (width × height): 3.5 × 3.5 ft.
Mounting Type: In-Ground.
Gate height: 43¼ inches.
Gap below the gate: 1½ inches.
Post spacing (center to center): 45⅝ inches.
Clear opening between posts: approximately 42⅜ inches.
Post height above ground: 45 inches, excluding the post cap.
Post depth below ground: 24 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
42 x 42-inch Welded Gate Frame: powder-coated aluminum.
Gate Frame Cover Strip: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
#8 x 1-1/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Groove Cover: powder-coated aluminum.
- Six Teak pieces join into one closed vertical gate face.
- Wood fibers and recycled plastic form the wood-grain composite infill.
- Teak surfaces resist moisture, insects, rot and fading without routine coatings.
- The welded aluminum gate frame connects to two galvanized steel post supports.
- Modern Yard™ 98-inch Steel Post x 2 PCs
- Modern Yard™ 42-inch x 42-inch Door Frame x 1 set
- Modern Yard™ Teak Fence Board x 1.5 packs (6 boards)
Limited warranty periods (residential / commercial use):
- Structural defects in Teak boards and covered metal gate parts: up to 25 / 10 years.
- Covered Teak board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently asked questions
Do I need six original Teak boards?
Yes. Each original supplies one cut piece for this frame. Two four-board packs provide the six boards needed for a gate ordered alone, leaving two unused. A combined order can total compatible stock across the fence and gate before rounding the packs.
Which posts support the small Teak leaf?
Use two 98-inch In-Ground steel post products. The finished layout has 45 inches above ground, excluding caps, and 24 inches below. Keep these small-gate dimensions when processing the posts.
Is the nominal width the clear opening?
The nominal size identifies the gate format. The drawing specifies approximately 42⅜ inches clear between posts and 45⅝ inches between their centers. Ground clearance is a separate 1½-inch dimension beneath the leaf.
