Redwood Composite Vertical 1 × 6 ft Decorative Panel, Pattern P01 Double Gate — 7 ft W × 6 ft H - In-Ground

Style #:

WPV/DGDP16P01RD8DP2-84X72-IG

Four upright Redwood boards and one P01 steel insert fill each leaf of this composite fence gate. The two welded aluminum frames create the nominal 7 × 6 ft double format, with eight composite pieces across the complete assembly.

Redwood wood-grain boards blend wood fibers and recycled plastic. Their faces resist moisture, insects, rot and fading without regular painting, staining or sealing. Private Black is the finish of the separate metal framing.

Two complete P01 source kits supply the patterned steel panels and aluminum decorative rails. The kits are processed for these leaves. Two four-board Redwood packs provide the eight originals required for the upright infill.

Assemble the infill on site and order the frames, two In-Ground steel posts, mechanical combination lock and outdoor handle set with drop rod separately. Compare the double-gate formats when planning composite fence systems with a paired opening.

  • Four upright Redwood boards and one P01 steel insert fill each leaf of this composite fence gate. The two welded aluminum frames create the nominal 7 × 6 ft double format, with eight composite pieces across the complete assembly.

    Redwood wood-grain boards blend wood fibers and recycled plastic. Their faces resist moisture, insects, rot and fading without regular painting, staining or sealing. Private Black is the finish of the separate metal framing.

    Two complete P01 source kits supply the patterned steel panels and aluminum decorative rails. The kits are processed for these leaves. Two four-board Redwood packs provide the eight originals required for the upright infill.

    Assemble the infill on site and order the frames, two In-Ground steel posts, mechanical combination lock and outdoor handle set with drop rod separately. Compare the double-gate formats when planning composite fence systems with a paired opening.

  • Engineering Dimensions

    Nominal size (width × height): 7 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 87⅜ inches.

    Clear opening between posts: approximately 84¼ inches.

    Post height above ground: 74 inches, excluding the post cap.

    Post depth below ground: 40 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Mechanical Combination Lock: 304 stainless steel.

    Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.

    #8 x 3/4" ST Screw: 316 stainless steel.

    Decorative Panel: electrocoated and powder-coated galvanized steel.

    Decorative Panel Top Rail: powder-coated aluminum.

    Decorative Panel Bottom Rail: powder-coated aluminum.

    Decorative Panel Side Rail: powder-coated aluminum.

    • Four vertical Redwood pieces and one P01 insert fill each aluminum frame.
    • Wood-grain composite resists fading, moisture, insects and rot.
    • Two decorative kits supply separate steel panels and aluminum rails.
    • The single project list covers both gate leaves and two end posts.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Redwood boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Redwood board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Redwood composite fence board with wood-look finish on a white background

Modern Yard™ Redwood Fence Board (4-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard stainless steel outdoor gate handle set with drop rod

Modern Yard™ Stainless Steel Outdoor Gate Handle Set with Drop Rod

Modern Yard 1 x 6 ft decorative fence panel with modern perforated metal design

Modern Yard™ 1 Foot x 6 Feet Fence Decorative Panel

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

The totals cover the pair: eight Redwood originals, two P01 kits, two frames and two posts. One mechanical combination lock serves the active leaf, and one outdoor handle set with drop rod serves the inactive leaf. Keep those complete-assembly quantities.

Steel forms the P01 panels, and aluminum forms their decorative rails. Redwood names the separate composite board color. The source kit's 1 × 6 ft name does not describe the finished double-gate dimensions.

Use two 114-inch In-Ground steel posts, with 74 inches above ground without caps and 40 inches below. When a fence panel shares a support location, count that post once and retain the gate's required post specification.
