Charcoal Composite Horizontal Semi-Privacy Double Gate with 1-Inch Gaps — 7 ft W × 6 ft H - In-Ground

Style #:

WPH/DGG10CH20-84X72-IG

Sixteen defined view openings run across the paired leaves of this Charcoal semi-privacy double gate. Each aluminum frame holds nine full horizontal composite pieces and a solid terminal strip, with eight 1-inch gaps. Nominal size is 7 ft W × 6 ft H.

The Private Black frames use In-Ground steel posts and matching center hardware. One leaf serves everyday access while the drop rod holds the companion; both can open for the wider entrance. This wood-look spaced pattern belongs to the composite gate range.

  • Sixteen defined view openings run across the paired leaves of this Charcoal semi-privacy double gate. Each aluminum frame holds nine full horizontal composite pieces and a solid terminal strip, with eight 1-inch gaps. Nominal size is 7 ft W × 6 ft H.

    The Private Black frames use In-Ground steel posts and matching center hardware. One leaf serves everyday access while the drop rod holds the companion; both can open for the wider entrance. This wood-look spaced pattern belongs to the composite gate range.

  • Engineering Dimensions

    Nominal size (width × height): 7 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 87⅜ inches.

    Clear opening between posts: approximately 84¼ inches.

    Post height above ground: 74 inches, excluding the post cap.

    Post depth below ground: 40 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Mechanical Combination Lock: 304 stainless steel.

    Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.

    #8 x 3/4" ST Screw: 316 stainless steel.

    1-inch Composite Spacer: powder-coated aluminum.

    • Charcoal composite fills the two leaves in a horizontal spaced arrangement.
    • A solid end strip finishes each nine-piece full-board stack.
    • Thirty-two spacers set sixteen one-inch openings across the pair.
    • These Charcoal boards resist moisture and insect damage.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Charcoal boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Charcoal board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Charcoal composite fence board with dark wood-look finish on a white background

Modern Yard™ Charcoal Fence Board (4-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard stainless steel outdoor gate handle set with drop rod

Modern Yard™ Stainless Steel Outdoor Gate Handle Set with Drop Rod

Modern Yard 1-inch spacer for horizontal fence installation

Modern Yard™ Accessory – 1-Inch Spacer for Horizontal Fence (40-Pack)

Imagine Your Future Fence

​Installation Guides

Cover of Composite double gate installation manual

Installation Manual

Engineering drawing cover for Charcoal Composite Horizontal Semi-Privacy Double Gate with 1-Inch Gaps — 7 ft W × 6 ft H - In-Ground (Style WPH/DGG10CH20-84X72-IG).

​Technical Drawing


Frequently asked questions

Each leaf has one solid strip.

Seven feet is nominal. The approximate clear opening is 84-1/4 inches; use the engineering dimensions with your Charcoal two-leaf quote.
