Redwood upright boards and Private Black base-plate posts form this Surface Mount composite fence. Sixteen short pieces fill the nominal 8 ft wide, 3 ft high section. The full-privacy fence style refers to the closed board face within that low height.
Wood fibers and recycled plastic make up the wood plastic composite boards. Their Redwood wood-grain finish offers a natural wood look, with resistance to moisture, decay, insects and fading. Routine board care needs no painting, staining or sealing. The vertical composite fence formats show the available board layouts for this composite fencing system.
The section uses one Vertical Fence Rail Set, with galvanized steel U rails and aluminum connectors. Two Redwood packs contain eight full-length composite boards; cutting them supplies the sixteen upright pieces. Order the boards, rails and fence posts as separate products.
Use the 74-inch post product with a welded base plate, trimmed at the top to this section's 38-inch finished height. Keep its welded base in place. Ground anchors are customer supplied. Count shared supports and free ends for the full fence run when preparing the material order.
Redwood upright boards and Private Black base-plate posts form this Surface Mount composite fence. Sixteen short pieces fill the nominal 8 ft wide, 3 ft high section. The full-privacy fence style refers to the closed board face within that low height.
Wood fibers and recycled plastic make up the wood plastic composite boards. Their Redwood wood-grain finish offers a natural wood look, with resistance to moisture, decay, insects and fading. Routine board care needs no painting, staining or sealing. The vertical composite fence formats show the available board layouts for this composite fencing system.
The section uses one Vertical Fence Rail Set, with galvanized steel U rails and aluminum connectors. Two Redwood packs contain eight full-length composite boards; cutting them supplies the sixteen upright pieces. Order the boards, rails and fence posts as separate products.
Use the 74-inch post product with a welded base plate, trimmed at the top to this section's 38-inch finished height. Keep its welded base in place. Ground anchors are customer supplied. Count shared supports and free ends for the full fence run when preparing the material order.
Engineering Dimensions
Nominal size (width × height): 8 × 3 ft.
Mounting Type: Surface Mount.
Fence height: 36 inches.
Gap below the fence: ½ inch.
Post spacing (center to center): 96⅜ inches.
Clear opening between posts: approximately 93¼ inches.
Post height above ground: 38 inches, excluding the post cap.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
74-inch Steel Post with Welded Base Plate: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
Composite Fence Board: wood-plastic composite (WPC).
Groove Cover: powder-coated aluminum.
U Rail: powder-coated galvanized steel.
End Cap: PA6.
Top Rail Connector: powder-coated aluminum.
Bottom Rail Connector: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
- The Redwood composite fence panel has sixteen upright pieces within a low, closed layout.
- Eight full-length boards yield the sixteen installed pieces, using two packs of material.
- Coated steel posts retain their welded base plates for Surface Mount.
- Redwood composite material resists moisture and decay without routine painting, staining or sealing.
- Modern Yard™ 74-inch Steel Post with Welded Base Plate x 1 PC
- Modern Yard™ Redwood Fence Board x 2 packs (8 full-length boards; 16 installed pieces after cutting)
- Modern Yard™ Vertical Fence Rail Set x 1 set
Limited warranty periods (residential / commercial use):
- Structural defects in Redwood boards and covered metal fence parts: up to 25 / 10 years.
- Covered Redwood board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently Asked Questions
Why is a 74-inch post listed for a three-foot fence?
The product name identifies the post stock. This layout trims its top to a 38-inch finished post height, including the welded base plate. It has no buried post section. Preserve the base and its mounting holes when preparing the post.
What should I buy for one independent section?
Allow for two base-plate posts, two four-board Redwood packs and one Vertical Fence Rail Set. Component Needs assigns one post per connected bay; an independent section also needs the other end support. Supply ground anchors separately and choose them for the installation surface.
What is the difference between the board finish and the metal finish?
Redwood is the wood-grain color of the composite infill. Private Black applies to the metal supports. Clean Redwood board faces with mild soap, water and a soft brush or cloth, avoiding harsh cleaners and abrasive tools.
