Charcoal Composite Horizontal 1 × 6 ft Decorative Panel, Pattern P01 Single Gate — 3.5 ft W × 6 ft H - In-Ground

Style #:

WPH/SGDP16P01CH9DP1-42X72-IG

Modern Yard composite single gates include this horizontal Charcoal design with a P01 steel insert. Nine wood-look board pieces and the patterned panel fill a Private Black welded aluminum frame. The leaf is nominally 3.5 ft wide by 6 ft high.

Charcoal boards have a UV-protected wrap over a core of wood fibers and recycled plastic. The faces resist moisture, fading, termites and decay. Aluminum decorative rails frame the separate steel insert. Compare the composite gate collection by board direction and infill pattern.

Assemble the infill within the welded frame on site. Purchase the board packs, P01 kit, frame and steel posts as separate products. The listed mechanical combination lock is another separate purchase. Its keyless mechanism operates without batteries or electrical power.

  • Modern Yard composite single gates include this horizontal Charcoal design with a P01 steel insert. Nine wood-look board pieces and the patterned panel fill a Private Black welded aluminum frame. The leaf is nominally 3.5 ft wide by 6 ft high.

    Charcoal boards have a UV-protected wrap over a core of wood fibers and recycled plastic. The faces resist moisture, fading, termites and decay. Aluminum decorative rails frame the separate steel insert. Compare the composite gate collection by board direction and infill pattern.

    Assemble the infill within the welded frame on site. Purchase the board packs, P01 kit, frame and steel posts as separate products. The listed mechanical combination lock is another separate purchase. Its keyless mechanism operates without batteries or electrical power.

  • Engineering Dimensions

    Nominal size (width × height): 3.5 × 6 ft.

    Mounting Type: In-Ground.

    Gate height: 72 inches.

    Gap below the gate: 1 inch.

    Post spacing (center to center): 45½ inches.

    Clear opening between posts: approximately 42⅜ inches.

    Post height above ground: 74 inches, excluding the post cap.

    Post depth below ground: 40 inches.

    Concrete footing width: 12 inches min.

    Hinge positions: 8 / 28½ / 8 inches.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    71 x 42-inch Welded Gate Frame: powder-coated aluminum.

    Gate Frame Cover Strip: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    #8 x 1-1/4" ST Screw: 410 stainless steel.

    #10 x 1" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Gate Stopper: powder-coated aluminum.

    Gate Stop Cover Plate: powder-coated aluminum.

    Hinge: powder-coated aluminum.

    Groove Cover: powder-coated aluminum.

    Mechanical Combination Lock: 304 stainless steel.

    Decorative Panel: electrocoated and powder-coated galvanized steel.

    Decorative Panel Top Rail: powder-coated aluminum.

    Decorative Panel Bottom Rail: powder-coated aluminum.

    Decorative Panel Side Rail: powder-coated aluminum.

    • Nine horizontal Charcoal pieces surround one P01 patterned steel insert.
    • A UV-protected wrap covers the Charcoal composite core.
    • Aluminum rails support the decorative panel within the gate layout.
    • The separate mechanical lock provides keyless operation without battery replacement.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Charcoal boards and covered metal gate parts: up to 25 / 10 years.
    • Covered Charcoal board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock is outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard Charcoal composite fence board with dark wood-look finish on a white background

Modern Yard™ Charcoal Fence Board (4-Pack)

Modern Yard 71 x 42 aluminum gate frame on a white background

Modern Yard™ 71 Inches x 42 Inches Gate Frame

Modern Yard 304 stainless steel mechanical combination gate lock

Modern Yard™ Stainless Steel Mechanical Combination Lock

Modern Yard 1 x 6 ft decorative fence panel with modern perforated metal design

Modern Yard™ 1 Foot x 6 Feet Fence Decorative Panel

Imagine Your Future Fence

​Installation Guides

Installation Manual

​Technical Drawing


Frequently asked questions

That name identifies the source kit. Its steel panel and aluminum rails fit this nominal 3.5 × 6 ft gate after processing. Use the gate's engineering opening dimensions when positioning the posts.

Three four-board packs supply twelve originals. Use nine for this gate and keep three unused. Total compatible Charcoal stock across the order before rounding the pack quantity.

The 114-inch steel posts extend 74 inches above ground and 40 below. The gate itself is 72 inches high, with a separate one-inch ground clearance.
