Get a better sense of your project cost and materials.


Ten Charcoal boards form this Modern Yard™ horizontal full privacy composite fence. Joined wood-grain faces fill the nominal 6 × 5 ft section between Private Black top and bottom rails.

Every infill board has the Charcoal finish. Its composite blends natural wood fibers with recycled polyethylene. Powder-coated galvanized steel makes the side posts, and powder-coated aluminum makes the horizontal rails.

Total the Charcoal boards across the project before ordering whole four-board packs. Compare horizontal composite fence system choices for other configurations.

  • Ten Charcoal boards form this Modern Yard™ horizontal full privacy composite fence. Joined wood-grain faces fill the nominal 6 × 5 ft section between Private Black top and bottom rails.

    Every infill board has the Charcoal finish. Its composite blends natural wood fibers with recycled polyethylene. Powder-coated galvanized steel makes the side posts, and powder-coated aluminum makes the horizontal rails.

    Total the Charcoal boards across the project before ordering whole four-board packs. Compare horizontal composite fence system choices for other configurations.

  • Engineering Dimensions

    Nominal size (width × height): 6 × 5 ft.

    Mounting Type: In-Ground.

    Fence height: 61 inches.

    Gap below the fence: ½ inch.

    Post spacing (center to center): 71½ inches.

    Clear opening between posts: approximately 68¼ inches.

    Post height above ground: 63 inches, excluding the post cap.

    Post depth below ground: 21 inches.

    Concrete footing width: 12 inches min.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    98-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    Top Rail: powder-coated aluminum.

    Bottom Rail: powder-coated aluminum.

    Horizontal Connector: aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    Composite Fence Board: wood-plastic composite (WPC).

    Groove Cover: powder-coated aluminum.

    • Ten Charcoal boards join through the full horizontal board stack.
    • Charcoal composite helps resist insect damage.
    • Powder-coated galvanized steel posts frame aluminum rails and composite infill.
    • Charcoal board faces need no regular painting or staining and no routine sealing.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Charcoal boards and covered metal fence parts: up to 25 / 10 years.
    • Covered Charcoal board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 98-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 98-Inches Steel Post

Modern Yard horizontal fence rail set with matching rail components on a white background

Modern Yard™ Horizontal Fence Rail Set

Modern Yard Charcoal composite fence board with dark wood-look finish on a white background

Modern Yard™ Charcoal Fence Board (4-Pack)

Imagine Your Future Fence

Installation Guides

Installation Manual

​Technical Drawing


Frequently Asked Questions

This section needs ten boards, rather than ten packs. Charcoal packs contain four boards each. Total the installed boards for the full project before ordering whole packs.

The side posts are galvanized steel. Aluminum rails finish the two horizontal edges. Private Black finishes both metal products around the Charcoal boards.

Two posts belong to a stand-alone section. Connected sections can share a post. Count the line, end, corner and gate post locations across your complete project.
