Keep Charcoal boards upright across these composite double gates. This composite fence gate has twelve vertical boards in two aluminum frames. One LINE crossbeam sits above the pair. This configuration is intended for a junction with a 7 ft fence; the gate leaves remain nominally 6 ft high.
The nominal 7 ft width describes the complete double fence gate, not either leaf or its clear opening. Two 114-inch steel posts use the specified 86-inch above-ground height and 28-inch embedment. Frames, boards, lock and handle set are separate purchasing items. The crossbeam allocation also needs its matching hardware. Compare the composite gate layouts before choosing this vertical version and its complete component list.
Keep Charcoal boards upright across these composite double gates. This composite fence gate has twelve vertical boards in two aluminum frames. One LINE crossbeam sits above the pair. This configuration is intended for a junction with a 7 ft fence; the gate leaves remain nominally 6 ft high.
The nominal 7 ft width describes the complete double fence gate, not either leaf or its clear opening. Two 114-inch steel posts use the specified 86-inch above-ground height and 28-inch embedment. Frames, boards, lock and handle set are separate purchasing items. The crossbeam allocation also needs its matching hardware. Compare the composite gate layouts before choosing this vertical version and its complete component list.
Engineering Dimensions
Nominal size (width × height): 7 × 6 ft.
Mounting Type: In-Ground.
Gate height: 72 inches.
Gap below the gate: 1 inch.
Post spacing (center to center): 87⅛ inches.
Clear opening between posts: approximately 84 inches.
Post height above ground: 86 inches, excluding the post cap.
Crossbeam top: 2 inches below the post top.
Post depth below ground: 28 inches.
Concrete footing width: 12 inches min.
Hinge positions: 8 / 28½ / 8 inches.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
114-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
71 x 42-inch Welded Gate Frame: powder-coated aluminum.
Gate Frame Cover Strip: powder-coated aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
#8 x 1-1/4" ST Screw: 410 stainless steel.
#10 x 1" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Gate Stopper: powder-coated aluminum.
Gate Stop Cover Plate: powder-coated aluminum.
Hinge: powder-coated aluminum.
Groove Cover: powder-coated aluminum.
Crossbeam: powder-coated galvanized steel.
Base Connector: powder-coated aluminum.
L Connector: 201 stainless steel.
Mechanical Combination Lock: 304 stainless steel.
Outdoor Gate Handle Set with Drop Rod: 304 stainless steel.
#8 x 3/4" ST Screw: 316 stainless steel.
- Twelve Charcoal composite boards form the vertical infill across both leaves.
- Two aluminum gate frames provide the on-site assembly route.
- One separate LINE crossbeam serves this 7 ft fence junction.
- The specified steel posts have 86 inches above ground and 28 inches below.
- Modern Yard™ 114-inch Steel Post x 2 PCs
- Modern Yard™ 71-inch x 42-inch Door Frame x 2 sets
- Modern Yard™ Charcoal Fence Board x 3 packs (12 boards)
- Modern Yard™ Stainless Steel Mechanical Combination Lock x 1 set
- Modern Yard™ Stainless Steel Outdoor Gate Handle Set with Drop Rod x 1 set
- Modern Yard Line™ Fence Slat x 0.5 pack (1 crossbeam after cutting)
- Modern Yard™ Full-Privacy Hardware Kit for 1-Inch Fence Slats x 0.5 set (Base Connector x 2 PCs, L Connector x 2 PCs, #8 x 3/4" ST Screw x 8 PCs)
Limited warranty periods (residential / commercial use):
- Structural defects in Charcoal boards and covered metal gate parts: up to 25 / 10 years.
- Covered Charcoal board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes. The combination lock and outdoor handle set are outside the periods listed above. Contact Modern Yard for the applicable separate warranty terms.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Related Components
Frequently asked questions
Are the twelve boards needed for each gate leaf?
No. Twelve boards are the total for the two-leaf configuration. The corresponding board allocation is three four-board packs; read the gate-frame and hardware quantities separately.
Does the crossbeam make these leaves 7 ft tall?
No. The leaves retain their nominal 6 ft height. The crossbeam and taller above-ground posts belong to the dedicated junction with a 7 ft fence.
Why does the materials list allocate half a LINE pack?
A LINE pack contains two stock slats. This double gate allocates one stock slat for one installed crossbeam. Complete-pack purchasing and leftover stock are handled for the project.
