Teak Composite Vertical Full Privacy Fence Panel — 8 ft W × 3 ft H - In-Ground

Style #:

WPV/FPTK16-96X36-IG

Teak gives this three-foot-high composite fence its wood-look face. Sixteen short, upright pieces fill the nominal eight-foot-wide section, creating closed infill between Private Black In-Ground steel posts.

The vertical rail set combines galvanized steel U-rails with aluminum connectors. Teak WPC boards blend wood fibers and recycled plastic, with no routine painting, staining or sealing required. The wider vertical composite fence system accommodates slopes, changes in elevation through stepped sections, and angled layouts using compatible connections.

  • Teak gives this three-foot-high composite fence its wood-look face. Sixteen short, upright pieces fill the nominal eight-foot-wide section, creating closed infill between Private Black In-Ground steel posts.

    The vertical rail set combines galvanized steel U-rails with aluminum connectors. Teak WPC boards blend wood fibers and recycled plastic, with no routine painting, staining or sealing required. The wider vertical composite fence system accommodates slopes, changes in elevation through stepped sections, and angled layouts using compatible connections.

  • Engineering Dimensions

    Nominal size (width × height): 8 × 3 ft.

    Mounting Type: In-Ground.

    Fence height: 36 inches.

    Gap below the fence: ½ inch.

    Post spacing (center to center): 96⅜ inches.

    Clear opening between posts: approximately 93¼ inches.

    Post height above ground: 38 inches, excluding the post cap.

    Post depth below ground: 12 inches.

    Concrete footing width: 12 inches min.

    Parts and Materials

    Standard Post Cap: powder-coated aluminum.

    114-inch Steel Post: powder-coated galvanized steel.

    3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).

    Composite Fence Board: wood-plastic composite (WPC).

    Groove Cover: powder-coated aluminum.

    U Rail: powder-coated galvanized steel.

    End Cap: PA6.

    Top Rail Connector: powder-coated aluminum.

    Bottom Rail Connector: powder-coated aluminum.

    #8 x 3/4" ST Screw: 410 stainless steel.

    • Teak wood grain pairs with Private Black metal framing.
    • The composite boards resist moisture, rot, insects and fading.
    • Two four-board packs supply the low panel's upright infill.
    • Teak board faces need no regular painting, staining or sealing.
  • Limited warranty periods (residential / commercial use):

    • Structural defects in Teak boards and covered metal fence parts: up to 25 / 10 years.
    • Covered Teak board color changes: up to 25 / 10 years.
    • Coastal metal coating defects: up to 5 / 3 years.
    • Non-coastal metal coating defects: up to 15 / 10 years.
    • Covered metal finish fading, all locations: up to 8 / 5 years.

    For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.

    Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.

    Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.

    Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.

    For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.

    Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.

    We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.

    Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.

Related Components

Modern Yard 114-inch galvanized steel fence post with compatible fence system components

Modern Yard™ 114-Inches Steel Post

Modern Yard vertical fence rail set with matching rail and mounting components

Modern Yard™ Vertical Fence Rail Set

Modern Yard Teak composite fence board with natural wood-look finish on a white background

Modern Yard™ Teak Fence Board (4-Pack)

Modern Yard standard fence post cap in dark powder-coated finish

Modern Yard™ Accessory – Standard Post Cap

Imagine Your Future Fence

Installation Guides

Cover of Vertical composite fence installation manual

Installation Manual

Engineering drawing cover for Teak Composite Vertical Full Privacy Fence Panel — 8 ft W × 3 ft H - In-Ground (Style WPV/FPTK16-96X36-IG).

​Technical Drawing


Frequently Asked Questions

The term describes this panel's closed board pattern. The fence height is three feet.

Split 114-inch stock and trim each support to the specified length.

This configuration uses In-Ground.
