This fence section uses ten horizontal Teak boards and one patterned P01 steel insert. Private Black posts and rails frame the infill.
Teak's wood-plastic composite blends wood fibers and recycled plastic. The P01 panel combines electrocoated, powder-coated galvanized steel and aluminum rails. Galvanized steel posts anchor the fence in the ground.
Compare layouts in the horizontal composite fence collection.
This fence section uses ten horizontal Teak boards and one patterned P01 steel insert. Private Black posts and rails frame the infill.
Teak's wood-plastic composite blends wood fibers and recycled plastic. The P01 panel combines electrocoated, powder-coated galvanized steel and aluminum rails. Galvanized steel posts anchor the fence in the ground.
Compare layouts in the horizontal composite fence collection.
Engineering Dimensions
Nominal size (width × height): 6 × 6 ft.
Mounting Type: In-Ground.
Fence height: 72 inches.
Gap below the fence: ½ inch.
Post spacing (center to center): 71½ inches.
Clear opening between posts: approximately 68¼ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 24 inches.
Concrete footing width: 12 inches min.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
98-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
Top Rail: powder-coated aluminum.
Bottom Rail: powder-coated aluminum.
Horizontal Connector: aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Groove Cover: powder-coated aluminum.
Decorative Panel: electrocoated and powder-coated galvanized steel.
Decorative Panel Top Rail: powder-coated aluminum.
Decorative Panel Bottom Rail: powder-coated aluminum.
Decorative Panel Side Rail: powder-coated aluminum.
- Ten Teak boards and one P01 steel insert give this horizontal fence its mixed-material layout.
- Teak wood grain on the composite board faces gives them a natural wood appearance.
- Clean the composite boards with mild soap, water and a soft brush or cloth.
- In-Ground steel posts support aluminum rails around the infill.
- Modern Yard™ 98-inch Steel Post x 1 PC
- Modern Yard™ Teak Fence Board x 2.5 packs (10 boards)
- Modern Yard™ 1 Foot x 6 Feet Fence Decorative Panel x 1 set
- Modern Yard™ Horizontal Fence Rail Set x 1 set
Limited warranty periods (residential / commercial use):
- Structural defects in Teak boards and covered metal fence parts: up to 25 / 10 years.
- Covered Teak board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently Asked Questions
Are the ten boards the complete infill requirement?
Ten boards supply the composite infill. Add one P01 decorative kit, plus the section’s rails, posts and specified accessories.
Does the 1 × 6 ft decorative-kit name describe the whole fence?
No. That is the decorative kit’s product size. The whole fence is nominally 6 × 6 ft, with separate finished-height and post-spacing measurements.
How do I count Teak board packs for several sections?
Add the Teak stock quantities for the whole order, then round up to complete packs. Do not round each section separately.
