Redwood wood-grain boards meet a Private Black P01 steel insert in this horizontal composite fence. Ten boards and one decorative module fill the nominal 6 × 6 ft section.
The Redwood core combines wood fibers and recycled plastic. Aluminum rails frame the composite boards and decorative steel separately. Galvanized steel posts support the In-Ground fence system. Browse the composite fencing range when choosing the board-and-metal combination.
Redwood wood-grain boards meet a Private Black P01 steel insert in this horizontal composite fence. Ten boards and one decorative module fill the nominal 6 × 6 ft section.
The Redwood core combines wood fibers and recycled plastic. Aluminum rails frame the composite boards and decorative steel separately. Galvanized steel posts support the In-Ground fence system. Browse the composite fencing range when choosing the board-and-metal combination.
Engineering Dimensions
Nominal size (width × height): 6 × 6 ft.
Mounting Type: In-Ground.
Fence height: 72 inches.
Gap below the fence: ½ inch.
Post spacing (center to center): 71½ inches.
Clear opening between posts: approximately 68¼ inches.
Post height above ground: 74 inches, excluding the post cap.
Post depth below ground: 24 inches.
Concrete footing width: 12 inches min.
Parts and Materials
Standard Post Cap: powder-coated aluminum.
98-inch Steel Post: powder-coated galvanized steel.
3/4" U-Channel Rubber Strip: PVC (polyvinyl chloride).
Top Rail: powder-coated aluminum.
Bottom Rail: powder-coated aluminum.
Horizontal Connector: aluminum.
#8 x 3/4" ST Screw: 410 stainless steel.
Composite Fence Board: wood-plastic composite (WPC).
Groove Cover: powder-coated aluminum.
Decorative Panel: electrocoated and powder-coated galvanized steel.
Decorative Panel Top Rail: powder-coated aluminum.
Decorative Panel Bottom Rail: powder-coated aluminum.
Decorative Panel Side Rail: powder-coated aluminum.
- Ten Redwood boards provide the horizontal wood-grain infill.
- One Pattern P01 steel panel adds the decorative detail.
- Separate aluminum rail components frame the two infill materials.
- Redwood composite surfaces need no routine painting or sealing.
- Modern Yard™ 98-inch Steel Post x 1 PC
- Modern Yard™ Redwood Fence Board x 2.5 packs (10 boards)
- Modern Yard™ 1 Foot x 6 Feet Fence Decorative Panel x 1 set
- Modern Yard™ Horizontal Fence Rail Set x 1 set
Limited warranty periods (residential / commercial use):
- Structural defects in Redwood boards and covered metal fence parts: up to 25 / 10 years.
- Covered Redwood board color changes: up to 25 / 10 years.
- Coastal metal coating defects: up to 5 / 3 years.
- Non-coastal metal coating defects: up to 15 / 10 years.
- Covered metal finish fading, all locations: up to 8 / 5 years.
For metal coating coverage, use the nearest shoreline of an ocean, sea or saltwater bay. Salt or brackish tidal estuaries also count. Measure in a straight line from the installed part. A distance of 10 miles or less is coastal; farther away is non-coastal.
Qualifying defects under normal use must meet the written terms, including color and coating claim conditions. Metal coverage applies only to covered parts and eligible factory finishes.
Normal airborne coastal salt and salt spray alone do not exclude qualifying coating claims. The metal warranty excludes direct saltwater immersion or splash damage.
Remaining coverage transfers with property ownership. Products must stay at the original site. Keep records of the products and original purchase date. Transfer or replacement does not restart coverage.
For approved claims, Modern Yard refunds or replaces defective boards or parts. The original net purchase price determines the amount. The amount drops over time under the warranty schedule.
Metal coating compensation is 100% in the term’s first half, 50% in the second. Other claims follow separate schedules.
We do not pay for labor, installation, removal, reinstallation, freight or shipping. This changes if required by law or if Modern Yard expressly agrees in writing.
Email service@mymodernyard.com with purchase records, photos, product details and the issue. Expect a decision or next steps within 7–14 business days. Contact Modern Yard for full warranty terms.
Frequently Asked Questions
Is the P01 insert another Redwood board?
P01 is a patterned galvanized steel panel with its own aluminum rails. It is separate from the ten composite boards.
How many Redwood packs should I allow for this panel?
Ten boards equal a 2.5-pack material share because each pack contains four pieces. Total the project's Redwood boards before purchasing complete packs.
Which rails should I buy with the decorative kit?
Buy one Horizontal Fence Rail Set for the Redwood infill. The P01 kit supplies its own rails for the decorative sheet. Steel posts are a separate product.
